AC380-13.25 | AC380 Acrylic VIS A/R Protective Window

Midwest Optical SystemsSKU: MID AC380-13.25
Lead Time: 15 Business Days

Price:
Sale price$39.00 USD

Shipping calculated at checkout

Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us.

Description

The MidOpt AC380-13.25 is an abrasion-, scratch-, breakage-, and solvent-resistant acrylic protection window that withstands harsh environments and is also half the weight of glass windows.

Compared to untreated acrylic, the vacuum-sputtered coatings applied to these windows are 50 times more scratch-resistant and impervious to all types of fuels and chemicals, especially chlorinated solvents, acetone, and MEK.

AC380 material blocks almost all UV light while averaging greater than 98% transmission in the 450-700nm visible spectrum. This protection window is a highly effective yet economical solution for covering camera enclosures and on-axis lighting. Available from stock in 2mm and 3mm thicknesses, custom sizes and shapes can be quickly laser cut in-house. This material is often used in FDA/EFSA applications.

*For 1mm thickness or standard 25.4™ C-Mount option, please see AC370. For filters thicker than 1mm, we offer an alternative C-mount mounting solution with an overall thickness of 5.5mm. This mount can accommodate filters up to 3.5mm thick.

All MidOpt filters can also be purchased unmounted and in custom dimensions upon request from Machine Vision Direct.

Technical Specifications
