SP-12401C-PGE JAI GigE Vision Area Scan Camera 1.1″ Format Color 12.4 MP 4088 × 3000 px 9 FPS

JAISKU: JAI SP-12401C-PGE

Price:
Sale price$3,090.00 USD

Shipping calculated at checkout

This is a Sample Product Title
Was $200.00 Now $100.00
Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us

Description

The SP-12401C-PGE provides 12-megapixel color resolution at up to 9.3 fps over a standard GigE Vision interface. Featuring the Sony Pregius IMX304 CMOS imager, it delivers outstanding low-noise image quality suitable for a wide range of high resolution machine vision applications.

Spark Series: High resolution area scan cameras

Spark Series area scan cameras are the perfect choice for machine vision applications demanding high quality images with the highest possible throughput. They feature the latest CMOS imagers delivering high resolution images at speeds as much as 10 times faster than traditional CCD cameras. For example, 45-megapixel (MP) models can deliver over 50 fps output while some 5-MP models run at 250 fps or more. Using the region-of-interest (ROI) feature, even higher frame rates can be achieved.

Technical Specifications

Product Line Spark Series
Model SP-12401C-PGE
Type Area Scan
Color/Monochrome Color
Light Spectrum Visible
Resolution 12.4 MP
Resolution WxH 4088 x 3000 px
Frame Rate/Line Rate 9 fps
ROI Yes
Interface GigE Vision 1-Cable (PoE)
Sensors 1xCMOS
Sensor Model IMX304
Optical Format 1.1 inch
Cell Size 3.45 x 3.45 µm
Shutter Global shutter
Sensor Diagonal 17.6 mm
Active Sensor Dimensions 14.2 x 10.4 mm
Camera Dimensions 44 x 44 x 54 mm
Weight 160 g
Video 8/10/12-bit
Lens Mount C-Mount
Power Consumption 4 Watt
Operating Temperature (Ambient) -5°C to +45°C
