AP-3200T-USB-LSX JAI USB3 Vision Area Scan Camera 1/1.8″ Format Color 3.2 MP 2064 × 1544 px 38 FPS

JAISKU: JAI AP-3200T-USB-LSX

Price:
Sale price$5,850.00 USD

Shipping calculated at checkout

This is a Sample Product Title
Was $200.00 Now $100.00
Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us

Description

The Apex AP-3200T-USB-LSX is a 3-CMOS prism-based R-G-B area scan camera intended for microscopy applications in the medical and life sciences markets. The camera features multi-sensor prism technology, providing better color fidelity and spatial precision than traditional Bayer color cameras, and is certified to JAI's highest grade of dust/FOD suppression standards for maximum image clarity.

The camera is built around the Pregius[TM] IMX265 1/1.8-inch sensor featuring 2064 x 1544 pixels and pixel sizes of 3.45 µm x 3.45 µm. A standard C-mount can be easily adapted to most types of digital microscopes or can be used with a variety of standard or telecentric lenses in larger systems.

The camera can be optionally ordered with the IR-cut filter removed (AP-3200T-USB-NF-LSX) for applications needing extended sensitivity in the red/NIR channel. Drivers/device adapters are available for the popular ImagePro software from Media Cybernetics (sold separately), as well as for the open source Micro-Manager software package.



Apex Medical & Life Sciences Solutions

Apex Medical & Life Sciences Solutions is a suite of 3-CMOS area scan cameras offering advanced color imaging capabilities for a wide range of applications in the medical and life sciences markets. The multi-sensor prism technology provides better color fidelity and spatial precision than traditional Bayer color cameras, while the USB3 Vision interface offers excellent plug-and-play compatibility. All Apex Medical models are fully integrated with two of the most popular microscopy software solutions – Image-Pro® from Media Cybernetics and the µManager open source software package.

Technical Specifications

Product Line Apex Medical Solutions
Model AP-3200T-USB-LSX
Type Area Scan
Color/Monochrome Color
Light Spectrum Visible + NIR
Resolution 3.2 MP
Resolution WxH 2064 x 1544 px
Frame Rate/Line Rate 38 fps
ROI Yes
Interface USB3 Vision (PoUSB)
Sensors 3xCMOS RGB
Sensor Model IMX265
Optical Format 1/1.8 inch
Cell Size 3.45 x 3.45 µm
Shutter Global shutter
Sensor Diagonal 8.9 mm
Active Sensor Dimensions 7.1 x 5.3 mm
Camera Dimensions 44 x 44 x 74 mm
Weight 170 g
Video 8/10/12-bit
Lens Mount C-Mount
Power Consumption 5.3 Watt
Operating Temperature (Ambient) -5°C to +45°C
