AP-3200T-PMCL JAI Camera Link Area Scan Camera 1/1.8″ Format Color 3.2 MP 2064 × 1544 px 55 FPS

JAISKU: AP-3200T-PMCL
Lead Time: 4-12 Weeks

Price:
Sale price$4,810.00 USD

Shipping calculated at checkout

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us.

Description

This price includes tariffs, based on the applicable tariff charges. This change is effective as of 04/30/2025. Pricing is subject to change and may fluctuate.

The Apex AP-3200T-PMCL is a 3-CMOS prism-based industrial R-G-B area scan camera delivering 3 x 3.2 megapixels at 55 frames/second. It provides better color fidelity and spatial resolution than traditional Bayer color cameras and is designed for color-critical imaging and inspection tasks in machine vision, life science and microscopy applications.

Apex Medical & Life Sciences Solutions

The Apex Series cameras are 3-sensor R-G-B prism cameras that separate the incoming light into red, green and blue wavelengths, which are directed to three separate image sensors. The cameras deliver exceptionally accurate R-G-B raw image data ideal for demanding color machine vision applications across a range of industries including pharmaceutical, electronics, printing/packaging and imaging in microscopy and medical diagnostics equipment.

Technical Specifications

Product Line Apex Series
Model AP-3200T-PMCL
Type Area Scan
Color/Monochrome Color
Light Spectrum Visible
Resolution 3.2 MP
Resolution WxH 2064 x 1544 px
Frame Rate/Line Rate 55 fps
ROI Yes
Interface Mini Camera Link (PoCL)
Sensors 3xCMOS RGB
Sensor Model IMX265
Optical Format 1/1.8 inch
Cell Size 3.45 x 3.45 µm
Shutter Global shutter
Sensor Diagonal 8.9 mm
Active Sensor Dimensions 7.1 x 5.3 mm
Camera Dimensions 44 x 44 x 74 mm
Weight 170 g
Video 8/10/12-bit
Lens Mount C-Mount
Power Consumption 6 Watt
Operating Temperature (Ambient) -5°C to +45°C
