APG 25R-AK Camera Enclosure Universal Arm, 7.5" Barrel, Glass Window and PG29 Cord Grip

Lead time: 1 Week

On Barrel Air Ports: Standard (No Air Fittings)
Pan Tilt Mount: No Pan Tilt Mount



  • Universal Mounting Arm
  • 7.5" Barrel Length
  • Glass Window
  • PG29 Split Cord Grip for Cable Entry
  • Good for Washdown Areas
  • Good for Highly Corrosive Areas

APG 25R Downloads
APG 25R Brochure/Datasheet
APG 25R CAD Models
(Contact Support@MachineVisionDirect.com for additional drawings)

APG 25R NEMA 6/IP67 Enclosure for Dirt, Dust and Caustic Washdown

The 25R enclosure is a compact, high performance enclosure for your small camera. It is constructed completely of 316 stainless steel for maximum corrosion resistance.

The 25R enclosure is provided with two IP68 rated cord grips capable of handling cable diameters of 3mm to 7mm. Cord grips capable of handling 5mm to 10mm are also available at no extra cost.

The enclosure design allows complete access to the camera and lens when the barrel is removed. All camera and lens adjustments can be made after the camera is mounted, taking the guesswork out of focus and f-stop settings.

The 25R enclosure is available in a variety of standard barrel lengths from 6″ to 13″. Barrel extensions and custom barrel lengths are also available.

The enclosure is available with either a glass or acrylic viewport.


  • Constructed for corrosive environments
  • Designed for smaller cameras
  • Meets IP67 standards
  • All 316 stainless steel construction
  • Available in various barrel lengths
  • Comes standard with glass or acrylic viewport
  • Comes with two IP68 rated cord grips
  • Enclosure is constructed of 316 stainless steel.
  • All fasteners and clinch nuts are 316 stainless steel.
  • Fasteners to mount your camera are included.
  • Interior size: 2.3″ diameter. Barrel length can be specified.
  • Fasteners to mount your camera are included.
Interior size with standard 6.4″ barrel is: 2.25″ (57 mm) dia. by 7.25″ (184 mm) in length.
Weight: 1.8 lb. (with 4.5″ barrel and glass viewport) (25R-DB)
Weight: 2.0 lb. (with 7.0″ barrel and acrylic viewport) (25R-AG)

NOTE: The construction of this enclosure does not meet standards for food applications.

Note: Contact Support@MachineVisionDirect.com for customization
