LSR900 IP65 Linear Light Bar (900mm)

Smart Vision LightsSKU: LSR900-WHI
Lead Time: 3 Business Days

Color: WHITE
Lens: Narrow 10 Deg (Standard)
Linear Polarizer: None
Price:
Sale price$1,307.00 USD

Shipping calculated at checkout

This is a Sample Product Title
Was $200.00 Now $100.00
Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us

Description

The LSR series is a SmartVisionLink™-enabled linear light that can produce over 340,000 lux and is offered in lengths up to 1200 mm. When used with the BTM-1000 Bluetooth accessory and the SmartVisionLink™ app, the LSR Series can have its intensity remotely adjusted. The LSR Series is easily mounted with the built-in T-slot rail system.

Recommended illumination usage: Bright Field, Direct Lighting, and Dark Field

Product Details

  • Built-in Multi-Drive allows for continuous or OverDrive strobe operation
  • PNP and NPN strobe input
  • 5-pin M12 quick connect
  • SmartVisionLink Enabled - SmartVisionLink™-enabled provides easy intensity adjustment in both continuous and OverDrive™ modes
  • Ability to control intensity for the entire light or for each 300mm length on 600mm and longer LSR's if using BTM-1000 Bluetooth Module

Smart Vision Lights 900 Technical Secifications

LSR900 Continuous Operation Specifications

Electrical Input 24VDC +/–5%
Input Current Max. 990 mA per 300 mm segment
Input Power Max. 23.8 W per 300 mm segment
PNP Trigger  2mA @ 4VDC
7mA @ 12VDC
13.4mA @ 24VDC
NPN Trigger 12mA @ Ground (0VDC)
Trigger Input PNP > +4 VDC (24 VDC max.) to activate OR NPN > GND (<1VDC) to activate (not both)
Mode Control  Connect pin 5 to 1-10 VDC (10 - 100% output);
24 VDC (Max)
Strobe Duration Min. 10 μs | Max. ∞
Strobe Trigger Latency 10 μs
Strobe Frequency Max 4 kHz or 1 / Duty Cycle as calculated, whichever is less.1
Duty Cycle Max. 10%1
Analog Intensity  The output is adjustable from 10% - 100% of intensity limit by a 1 - 10 VDC signal. Jumpering pin 5 to pin 1 will provide maximum intensity.
Intensity limit can be remotely adjusted via SmartVisionLink™
2
Connection 5-pin M12 connector
Operating Temerature 10° to 40° C (14° to 104° F) | RH max 80% non-condensing humidity
Storage Temperature  20° to 70° C ( -4° to 158° F) | RH max 80% non-condensing humidity
Ip Rating IP65
Weight  LSR300: 1.8 lbs (~816 g) | LSR600: 3.2 lbs (~1.45 kg)
LSR900: 4.8 lbs (~2.17 kg) | LSR1200: 6.5 lbs (~2.95 kg)

Compliances CE, IEC-62471, RoHS
Warranty 10 years



LSR900 OverDrive Operation Specifications

Electrical Input 24VDC +/–5%
Input Current Max. 5.1 A per 300 mm segment
Input Power Max. 122 W per 300 mm segment
PNP Trigger  2mA @ 4VDC
7mA @ 12VDC
13.4mA @ 24VDC
NPN Trigger 12mA @ Ground (0VDC)
Trigger Input PNP > +4 VDC (24 VDC max.) to activate or
NPN > GND (<1VDC) to activate (not both)
Mode Control  Connect pin 5 to GND
(See wiring configuration for more information)
Strobe Duration Min. 10 μs | Max. 50 ms
Strobe Trigger Latency 6 μs
Strobe Frequency Max 4 kHz or 1 / Duty Cycle as calculated, whichever is less.1
Duty Cycle Not applicable
Analog Intensity  The output is adjustable from 10% - 100% of intensity limit by a 1 - 10 VDC signal. Jumpering pin 5 to pin 1 will provide maximum intensity.
Intensity limit can be remotely adjusted via SmartVisionLink™
2
Connection 5-pin M12 connector
Operating Temerature 10° to 40° C (14° to 104° F) | RH max 80% non-condensing humidity
Storage Temperature  20° to 70° C ( -4° to 158° F) | RH max 80% non-condensing humidity
Ip Rating IP65
Weight  LSR300: 1.8 lbs (~816 g) | LSR600: 3.2 lbs (~1.45 kg)
LSR900: 4.8 lbs (~2.17 kg) | LSR1200: 6.5 lbs (~2.95 kg)

Compliances CE, IEC-62471, RoHS
Warranty 10 years



Lens Options

The LSR900 from Smart Vision Lights is available in three lens variations

Lens Option Beam Angle

Narrow 10 Deg

(Standard)

10 Degrees

The standard lens option uses a 10° beam angle lens. Standard lenses create a narrow beam of illumination and are used for long working distances.

Wide Lens

30 Degrees

Wide, 30° angle-cone lenses create a large area of illumination. They create a floodlight effect and can be used for shorter working distances.

Line Lens

10 x 50 Degrees

The line lens option uses a 10° x 50° beam angle lens. They
project a thin, narrow beam of illumination.



Working Distance

Smart Vision Lights recommends the LSR Series be used at a working distance between 200 mm to 2000 mm

Smart Vision Link

With integrated SmartVisionLink™, the LSR900 can be used with Smart Vision Light’s Bluetooth module (BTM-1000*). Users can install the SmartVisionLink™ app on Android or Apple phones and tablets to configure lighting parameters for each of the four lighting zones. Zone parameters include 10-100% intensity for both continuous and OverDrive™ strobe modes, as well as zone-disable. After parameters are set and saved, the BTM-1000 can be removed from the LSR900 and settings will be retained in LSR900E’s static memory. The SmartVisionlink™ app is available at no cost from the Google Play Store or Apple’s App Store. Smart Vision Link

*The BTM-1000 is sold separately.

Connecting a BTM-1000 Module

The BTM-1000 can be connected directly to a light or attached to a jumper cable that is connected to a light. Once the light's intensity is set to desired level, the BTM-1000 can be removed from the light or cable. The pigtail end of the BTM-1000 is connected directly to the light or to the cable attached to the light.

BTM-1000 Module on Smart Vision Lights LTF300
(LTF300 Light shown above)

Wavelength Colors
LXE300 Wavelengths Smart Vision Lights

For colors not listed or available online, contact Support@MachineVisionDirect.com

Multi-Drive Wiring
Wiring Configuration for CONSTANT ON Operation
Wiring Configuration for STROBE/PULSE Overdrive Operation

MOUNTING
The LSR Series is easily mounted with the built-in T-slot rail system.
Smart Vision Lights SVL LSR Mounting

LSR900 Downloads

LSR900 Datasheet | Smart Vision Lights
LSR900 3D STEP Model | Smart Vision Lights
Smart Vision Lights LSR900 2D Drawing | Machine Vision Direct
