AP-1600T-USB JAI USB3 Vision Area Scan Camera 1/2.9″ Format Color 1.6 MP 1456 × 1088 px 79 FPS

JAISKU: AP-1600T-USB
Lead Time: 4-12 Weeks

Price:
Sale price$3,009.00 USD

Shipping calculated at checkout

Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us

Description

This price includes tariffs, based on the applicable tariff charges. This change is effective as of 04/30/2025. Pricing is subject to change and may fluctuate.

The Apex AP-1600T-USB is a 3-CMOS prism-based industrial R-G-B area scan camera providing better color fidelity and spatial precision than traditional Bayer color cameras. The camera is built around the PregiusTM IMX273 1/2.9-inch sensor featuring 1456 x 1088 pixels and pixel sizes of 3.45 µm x 3.45 µm. The USB3 Vision interface offers excellent plug and play compatibility while delivering 3 x 1.6 megapixels at nearly 79 frames/second.

The camera can be optionally ordered with the IR-cut filter removed (AP-1600T-USB-NF) for applications needing extended sensitivity in the red/NIR channel. It is loaded with a range of advanced features and functions supporting the most challenging color imaging applications in machine vision, life sciences, and industrial microscopy.

Apex Medical & Life Sciences Solutions

The Apex Series cameras are 3-sensor R-G-B prism cameras that separate the incoming light into red, green and blue wavelengths, which are directed to three separate image sensors. The cameras deliver exceptionally accurate R-G-B raw image data ideal for demanding color machine vision applications across a range of industries including pharmaceutical, electronics, printing/packaging and imaging in microscopy and medical diagnostics equipment.

Technical Specifications

Product Line Apex Series
Model AP-1600T-USB
Type Area Scan
Color/Monochrome Color
Light Spectrum Visible + NIR
Resolution 1.6 MP
Resolution WxH 1456 x 1088 px
Frame Rate/Line Rate 79 fps
ROI Yes
Interface USB3 Vision (PoUSB)
Sensors 3xCMOS RGB
Sensor Model IMX273
Optical Format 1/2.9 inch
Cell Size 3.45 x 3.45 µm
Shutter Global shutter
Sensor Diagonal 6.3 mm
Active Sensor Dimensions 5.0 x 3.8 mm
Camera Dimensions 44 x 44 x 74 mm
Weight 170 g
Video 8/10/12-bit
Lens Mount C-Mount
Power Consumption 5.3 Watt
Operating Temperature (Ambient) -5°C to +45°C
