FS-1600D-10GE JAI 10GigE Vision Area Scan Camera 1/2.9″ Format Multispectral 1.6 MP 1440 × 1080 px 226 FPS

JAISKU: JAI FS-1600D-10GE
Lead Time: 4-12 Weeks

Price:
Sale price$2,150.00 USD

Shipping calculated at checkout

Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us

Description

This price includes tariffs, based on the applicable tariff charges. This change is effective as of 04/30/2025. Pricing is subject to change and may fluctuate.

JAI's FS-1600D-10GE is a 2-CMOS multispectral prism camera providing simultaneous images of different spectral bands in a single camera - a visible color channel from 400-670 nm and a near infrared (NIR) channel from 740-1000 nm. This makes it possible to simultaneously inspect surface properties and sub-surface defects. A backwards-compatible 10 GigE interface provides exceptional speed and networking flexibility.

Fusion Series: multi-sensor, multispectral area scan cameras

JAI's Fusion Series of multispectral prism cameras provide simultaneous images of multiple wavebands through a single optical path. The cameras split incoming light into two or three separate sensors with precise pixel-to-pixel alignment regardless of motion or viewing angle. Fusion Series cameras are ideal for life sciences or surgical applications using NIR fluorescence; for intelligent farming techniques such as NDVI/NDRE vegetation analysis or autonomous weed removal systems; for fruit, vegetable, and other types of food sorting or inspection; for electronics/PCB inspection; and much more.

Technical Specifications

Product Line Fusion Series
Model FS-1600D-10GE
Type Area Scan
Color/Monochrome Multispectral
Light Spectrum 2-Bands Visible + NIR
Resolution 1.6 MP
Resolution WxH 1440 x 1080 px
Frame Rate/Line Rate 226 fps
ROI Yes
Interface 10 Gbps GigE Vision
Sensors 2xCMOS (Vis/NIR)
Sensor Model IMX273
Optical Format 1/2.9 inch
Cell Size 3.45 x 3.45 µm
Shutter Global shutter
Sensor Diagonal 6.2 mm
Active Sensor Dimensions 5.0 x 3.7 mm
Camera Dimensions 62 x 62 x 86.5 mm
Weight 270 g
Video 8/10/12-bit
Lens Mount C-Mount
Power Consumption 10.4 Watt
Operating Temperature (Ambient) -5°C to +45°C
