The SW-2001T-CL is a high performance prism-based industrial RGB color line scan camera with three separate imagers for simultaneously capturing red, green and blue light. Through advanced prism technology it provides the best possible performance and precision for web-based or continuous imaging applications.
Sweep+ Series: 3 and 4-sensor color line scan cameras
The Sweep+ Series comprises 3-sensor R-G-B and 4-sensor R-G-B-NIR or R-G-B-SWIR line scan cameras for industrial machine vision applications. They features state-off-the-art prism technology providing the best possible performance, precision, and versatility for line scan imaging in continuous production flows.
Technical Specifications
Product Line | Sweep+ Series |
Model | SW-2001T-CL-F |
Type | Line Scan |
Color/Monochrome | Color |
Light Spectrum | Visible |
Resolution | N/A |
Resolution WxH | 2048 x 1 px |
Frame Rate/Line Rate | 19 kHz |
ROI | N/A |
Interface | Camera Link |
Sensors | 3xCCD RGB |
Sensor Model | N/A |
Optical Format | 28.67 mm |
Cell Size | 14.0 x 14.0 µm |
Shutter | Global shutter |
Sensor Diagonal | 28.7 mm |
Active Sensor Dimensions | 28.7 mm |
Camera Dimensions | 90 x 90 x 90 mm |
Weight | 830 g |
Video | |
Lens Mount | F-Mount |
Power Consumption | 12 Watt |
Operating Temperature (Ambient) | -5°C to +45°C |
