Kowa LM35XC 35 mm 4/3″ f/2 - f/16 C-Mount Fixed Focal Length Lens

Ahorrar $536.00
KowaSKU: LM35XC
Lead Time: Not Specified

Precio:
Precio de venta$994.00 USD Precio habitual$1,530.00 USD

Gastos de envío calculados en la caja

Downloads

Lead Times

Lead Times are estimated based on standard product lead times, but are subject to change. For the latest product lead times, we always recommend contacting us

Descripción

This price includes tariffs, based on the applicable tariff charges. This change is effective originally as of 05/30/25. Updated 06/04/25, 6/24/25. Pricing is subject to change and may fluctuate.

Kowa LM35XC

The 2/3″ 10 megapixel JC10M lens series provides 200lp/mm resolution and low distortion to maximize performance for high-end applications. Incorporating Kowa's broadband coating and floating mechanism design, the JC10M lens series dramatically reduces chromatic aberration at any distance and maintains a high transmission from visible to NIR.

LM35XC Technical Specifications:

Product Line / Series XC
Lens Type Fixed Focal Length
IP Rating Not Specified
Focal Length 35 mm
ƒ/N ƒ/2 - ƒ/16
Image Circle Diameter 23 mm
Image Size Dimensions 18.4 mm x 13.8 mm
Imager Format 4/3″
Light Spectrum Visible
Resolution (MP) 20
Resolution (Pixel Size) 3 μm
Resolution (Line Pairs per mm @ Center) 160
Resolution (Line Pairs per mm @ Corner) 80
Weight 210 Grams
Mount C-Mount
Filter Thread M37.5-0.5
Minimum Object Distance 200 mm
Magnification 0.18×
Minimum Object Distance with 1mm Ring 174 mm
Minimum Object Distance with 5mm Ring 117 mm
Minimum Object Distance with 10mm Ring 85 mm
Minimum Object Distance with 20mm Ring 58 mm
Magnification with 1mm Ring 0.21×
Magnification with 5mm Ring 0.33×
Magnification with 10mm Ring 0.48×
Magnification with 20mm Ring 0.77×
Front Diameter 26.5 mm
Rear Effective Diameter 16.9 mm
Focus Control Manual
Iris Control Manual
Focus Range 0.2 m - ∞
Back Focal Length 15.2 mm in air
Operating Temperature Range -10 to +50 °C
Storage Temperature Range -20 to +60 °C
Dimensions 45 × 45 × 74 mm
Shooting Range at MOD 100.3(H)×75.3(V)
TV Distortion (%) −0.17
Angle of View @ 2/3″ 14.3° × 10.8°
Angle of View @ 1″ 20.8° × 15.6°
Angle of View @ 1.1″ 22.8° × 17.2°
Angle of View @ 4/3″ 29.6° × 22.4°
