Descripción
Kowa LM25XC
The 2/3″ 10 megapixel JC10M lens series provides 200lp/mm resolution and low distortion to maximize performance for high-end applications. Incorporating Kowa's broadband coating and floating mechanism design, the JC10M lens series dramatically reduces chromatic aberration at any distance and maintains a high transmission from visible to NIR.
LM25XC Technical Specifications:
Product Line / Series | XC |
Lens Type | Fixed Focal Length |
IP Rating | Not Specified |
Focal Length | 25 mm |
ƒ/N | ƒ/2 - ƒ/16 |
Image Circle Diameter | 23 mm |
Image Size Dimensions | 18.4 mm x 13.8 mm |
Imager Format | 4/3″ |
Light Spectrum | Visible |
Resolution (MP) | 20 |
Resolution (Pixel Size) | 3 μm |
Resolution (Line Pairs per mm @ Center) | 160 |
Resolution (Line Pairs per mm @ Corner) | 80 |
Weight | 255 Grams |
Mount | C-Mount |
Filter Thread | M40.5-0.5 |
Minimum Object Distance | 150 mm |
Magnification | 0.15× |
Minimum Object Distance with 1mm Ring | 115 mm |
Minimum Object Distance with 5mm Ring | 56 mm |
Minimum Object Distance with 10mm Ring | 31 mm |
Minimum Object Distance with 20mm Ring | 12 mm |
Magnification with 1mm Ring | 0.19× |
Magnification with 5mm Ring | 0.35× |
Magnification with 10mm Ring | 0.55× |
Magnification with 20mm Ring | 0.96× |
Front Diameter | 31.4 mm |
Rear Effective Diameter | 18.2 mm |
Focus Control | Manual |
Iris Control | Manual |
Focus Range | 0.15 m - ∞ |
Back Focal Length | 24.3 mm in air |
Operating Temperature Range | -10 to +50 °C |
Storage Temperature Range | -20 to +60 °C |
Dimensions | 45 × 45 × 89 mm |
Shooting Range at MOD | 124.8(H)×93.0(V) |
TV Distortion (%) | −0.57 |
Angle of View @ 2/3″ | 20.1° × 15.2° |
Angle of View @ 1″ | 28.9° × 21.8° |
Angle of View @ 1.1″ | 31.8° × 24.0° |
Angle of View @ 4/3″ | 40.9° × 31.1° |
